Magnetic Properties of Ferrite Magnets--- In Chinese Standard:
|
Magnetic Properties of Ferrite Magnets(CN) |
|
Material |
Br |
HcB |
HcJ |
(BH) Max |
|
mT |
KG |
KA/m |
KOe |
KA/m |
KOe |
Kj/M3 |
MGOe |
|
Y10T |
200-235 |
2.0-2.35 |
125-160 |
1.57-2.01 |
210-280 |
2.64-3.52 |
6.5-9.5 |
0.8-1.2 |
|
Y20 |
320-380 |
3.2-3.8 |
135-190 |
1.70-2.38 |
140-195 |
1.76-2.45 |
18.0-22.0 |
2.3-2.8 |
|
Y22H |
310-360 |
3.1-3.6 |
220-250 |
2.77-3.14 |
280-320 |
3.52-4.02 |
20..0-24.0 |
2.5-3.0 |
|
Y23 |
320-370 |
3.2-3.7 |
170-190 |
2.14-2.38 |
190-320 |
2.39-2.89 |
20.0-25.5 |
2.5-3.2 |
|
Y25 |
360-400 |
3.6-4.0 |
135-170 |
1.70-2.14 |
140-200 |
1.76-2.51 |
22.5-28.0 |
2.8-3.5 |
|
Y26H |
360-390 |
3.6-3.9 |
220-250 |
2.77-3.14 |
225-255 |
2.83-3.21 |
23.0-29.0 |
2.9-3.5 |
|
Y27H |
370-400 |
3.7-4.0 |
205-250 |
2.58-3.14 |
210-255 |
2.64-3.21 |
25.0-29.0 |
3.1-3.7 |
|
Y30 |
370-400 |
3.7-4.0 |
175-210 |
2.20-2.64 |
180-220 |
2.26-2.77 |
26.0-30.0 |
3.3-3.8 |
|
Y30BH |
380-390 |
3.8-3.9 |
223-235 |
2.80-2.95 |
231-245 |
2.90-4.21 |
27.0-30.0 |
3.4-3.7 |
|
Y30-1 |
380-400 |
3.8-4.0 |
230-275 |
2.89-3.46 |
235-290 |
2.95-3.65 |
27.0-32.0 |
3.4-4.0 |
|
Y20-2 |
395-415 |
3.95-4.15 |
275-300 |
3.46-3.77 |
310-335 |
3.90-4.21 |
28.5-32.5 |
3.5-4.0 |
|
Y32 |
400-420 |
4.0-4.2 |
160-190 |
2.01-2.38 |
165-195 |
2.07-2.45 |
30.0-33.5 |
3.8-4.2 |
|
Y33 |
410-430 |
4.1-4.3 |
220-250 |
2.77-3.14 |
225-255 |
2.83-3.21 |
31.5-35.0 |
4.0-4.4 |
|
Y35 |
400-410 |
4.0-4.1 |
175-195 |
2.20-2.45 |
180-200 |
2.26-2.51 |
30.0-32.0 |
3.8-4.0 |
Magnetic Properties of Ferrite Magents------In Europe Standard:
|
Magnetic Properties of Ferrite Magnets(EU) |
|
Material |
Br |
HcB |
HcJ |
(BH) Max |
|
mT |
KG |
KA/m |
KOe |
KA/m |
KOe |
Kj/M3 |
MGOe |
|
HF8/22 |
200-220 |
2.00-2.20 |
125-140 |
1.57-1.76 |
220-230 |
2.76-2.89 |
6.5-6.8 |
0.8-1.1 |
|
HF20/19 |
320-333 |
3.20-3.33 |
170-190 |
2.14-2.39 |
190-200 |
2.39-2.51 |
20.0-21.0 |
2.5-2.7 |
|
HF20/28 |
310-325 |
3.10-3.25 |
220-230 |
2.76-2.89 |
280-290 |
3.52-2.64 |
20.0-21.0 |
2.5-2.7 |
|
HF22/30 |
350-365 |
3.50-3.65 |
255-265 |
3.20-3.33 |
290-300 |
3.64-3.77 |
22.0-23.5 |
2.8-3.0 |
|
HF24/16 |
350-365 |
3.50-3.65 |
155-175 |
1.95-2.20 |
160-180 |
2.01-2.26 |
24.0-25.5 |
3.0-3.2 |
|
HF24/23 |
350-365 |
3.50-3.65 |
220-230 |
2.76-2.89 |
230-240 |
2.89-3.01 |
24.0-25.5 |
3.0-3.2 |
|
HF24/35 |
360-370 |
3.60-3.70 |
260-270 |
3.27-2.29 |
350-360 |
4.40-4.52 |
24.0-25.5 |
3.0-3.2 |
|
HF26/16 |
370-380 |
3.70-3.80 |
155-175 |
1.95-2.20 |
160-180 |
2.01-2.26 |
26.0-27.0 |
3.2-3.4 |
|
HF26/18 |
370-380 |
3.70-3.80 |
175-190 |
2.20-2.39 |
180-190 |
2.26-2.39 |
26.0-27.0 |
3.2-3.4 |
|
HF26/24 |
370-380 |
3.70-3.80 |
230-240 |
2.89-3.01 |
240-250 |
3.01-3.14 |
26.0-27.0 |
3.2-3.4 |
|
HF26/26 |
370-380 |
3.70-3.80 |
230-240 |
2.89-3.01 |
260-270 |
3.27-3.39 |
26.0-27.0 |
3.2-3.4 |
|
HF26/30 |
385-395 |
3.85-3.95 |
260-270 |
3.27-2.29 |
280-290 |
3.77-3.89 |
26.0-27.0 |
3.2-3.4 |
|
HF28/26 |
385-395 |
3.70-3.80 |
250-265 |
3.14-3.33 |
260-275 |
3.27-3.45 |
28.0-30.0 |
3.5-3.8 |
|
HF28/28 |
385-395 |
3.70-3.80 |
260-270 |
3.27-3.39 |
280-290 |
3.50-3.60 |
28.0-30.0 |
3.5-3.8 |
|
HF30/26 |
395-405 |
3.95-4.05 |
250-260 |
3.14-3.33 |
260-270 |
3.27-3.39 |
30.0-31.5 |
3.8-3.9 |
|
HF32/17 |
410-420 |
4.10-4.20 |
160-180 |
2.01-2.26 |
165-175 |
2.07-2.20 |
32.0-33.0 |
4.0-4.1 |
|
HF32/22 |
410-420 |
4.10-4.20 |
215-225 |
2.70-2.83 |
220-230 |
2.76-2.89 |
32.0-33.0 |
4.0-4.1 |
|
HF32/25 |
410-420 |
4.10-4.20 |
240-250 |
3.01-3.14 |
250-260 |
3.14-3.27 |
32.0-33.0 |
4.0-4.1 |
Magnetic Properties of Ferrite Magents------In USA Standard:
|
Magnetic Properties of Ferrite Magnets(USA) |
|
Material |
Br |
HcB |
HcJ |
(BH) Max |
|
mT |
KG |
KA/m |
KOe |
KA/m |
KOe |
Kj/M3 |
MGOe |
|
C1 |
230 |
2.3 |
148 |
1.86 |
258 |
3.50 |
8.36 |
1.05 |
|
C5 |
380 |
3.8 |
191 |
2.40 |
199 |
2.50 |
27.0 |
3.40 |
|
C7 |
340 |
3.4 |
258 |
3.23 |
318 |
4.00 |
21.9 |
2.75 |
|
C8 |
385 |
3.85 |
235 |
2.95 |
242 |
3.05 |
27.8 |
3.50 |
|
C8B |
420 |
4.2 |
232 |
2.913 |
236 |
2.96 |
32.8 |
4.12 |
|
C9 |
380 |
3.8 |
280 |
3.516 |
320 |
4.01 |
26.4 |
3.32 |
|
C10 |
400 |
4.0 |
288 |
3.617 |
280 |
3.51 |
30.4 |
3.82 |
|
C11 |
430 |
4.3 |
200 |
2.512 |
204 |
2.56 |
34.4 |
4.32 | |
|
